Name
|
Teltonika TM2500
|
|
GNSS
|
GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
|
|
Receiver
|
33 tracking channel
99 acquisition channel
|
|
Tracking sensitivity
|
-165 dBM
|
|
Position Accuracy
|
< 2.5 m CEP
|
|
Velocity Accuracy
|
< 0.1 m/s (within +/- 15% error)
|
|
Hot start
|
< 1 s
|
|
Warm start
|
< 25 s
|
|
Cold start
|
< 35 s
|
|
Technology
|
GSM
|
|
2G bands
|
Quad-band 850 / 900 / 1800 / 1900 MHz
|
|
Data transfer
|
GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B
|
|
Data support
|
SMS (text/data)
|
|
Input voltage range
|
10–30 V DC with overvoltage protection
|
|
Internal Back-up battery
|
170 mAh Li-Ion battery, 3.7 V (0.63 Wh)
|
|
Internal fuse
|
3A, 125V
|
|
Power consumption
|
At 12V < 2 mA (Ultra Deep Sleep)
At 12V < 4 mA (Deep Sleep)
At 12V < 5 mA (Online Sleep)
At 12V < 6 mA (GPS Sleep)
At 12V < 25 mA (nominal)
|
|
Specification
|
4.0 + LE
|
|
Supported peripherals
|
EYE beacon and sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Bluetooth ® LE beacons and sensors support
|
|
Dimensions
|
65 x 56,6 x 18,9 mm (L x W x H)
|
|
Weight
|
51 g
|
|
Operating temperature (without battery)
|
-40 °C to +85 °C
|
|
Storage temperature (without battery)
|
-40 °C to +85 °C
|
|
Operating humidity
|
5% to 95% non-condensing
|
|
Ingress Protection Rating
|
IP41
|
|
Battery charge temperature
|
0 °C to +45 °C
|
|
Battery discharge temperature
|
-20 °C to +60 °C
|
|
Battery storage temperature
|
-20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months
|
|
Operating temperature (with battery)
|
-20 °C to +40 °C
|
|
Digital Inputs
|
3
|
|
Digital Outputs
|
2
|
|
Analog Inputs
|
2
|
|
CAN Adapter Inputs
|
1
|
|
1-Wire
|
1
|
|
GNSS antenna
|
External (MMCX connector) High Gain
|
|
Cellular antenna
|
Internal High Gain
|
|
USB
|
2.0 Micro-USB
|
|
LED indication
|
2 status LED lights
|
|
SIM
|
Dual SIM
|
|
Memory
|
128MB internal flash memory
|
|
Sensors
|
Accelerometer
|
|
Scenarios
|
Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip
|
|
Sleep modes
|
GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
|
|
Configuration and firmware update
|
FOTA WEB, FOTA, Teltonika Configurator (USB, Bluetooth®)
|
|
SMS
|
Configuration, Events, DOUT control, Debug
|
|
GPRS commands
|
Configuration, DOUT control, Debug
|
|
Time Synchronization
|
GNSS, NITZ, NTP
|
|
Fuel monitoring
|
LLS (Analog), OBDII dongle
|
|
Ignition detection
|
Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (OBDII dongle)
|
|
Regulatory
|
CE/RED, E-Mark, EAC, RoHS, REACH, Anatel, ICASA, SIRIM QAS, SDPPI POSTEL
|
