Home Fingerprint terminals Virdi 4000
Virdi AC-2100
Virdi AC-2100
Back to products
TC-C32KS
TC-C32KS

Virdi 4000

  • Graphic User Interface provides the easy navigation in the system and allows for personalisation of the display (eg. Background, corporate logo etc.)
  • Displays user’s picture during authorisation, using 1.3M Pixel Digital Camera and allows administrator to compare picture log data with user’s name or ID
  • Enables firmware upgrade and backup of Fingerprint templates
Add to wishlist
Category: Fingerprint terminals
Share:
  • Description
  • Additional information
  • Shipping & Delivery
Description

Fingerprint & RF/SC card authentication

Live finger detection: New patented sensor detects fake fingerprints made of paper, film, silicone and rubber

Fingerprint: Convenience – it does not require users to carry special tools for verification. It is a high-tech fingerprint recognition system that uses fingerprints that have no risk of replication or unauthorized use.

RF Cards (option): Can be embedded in the fingerprint recognition terminal for double or triple security or to use with unclear fingerprints.

Standalone: User management from the device

USB Interface: USB Interface for management via PC

Excellent Waterproofing: IPX3 rating the international waterproofing standard! It can be installed in virtually any location.

Duress Finger: In case of emergency, the usage of a registered duress fingerprint warns a control center such as security company.

Intelligent Capture: The fingerprint recognition algorithm authenticates dry or wet fingerprints fast and accurately for various users.

Highperformance CPU: The terminal is equipped with high-capacity 32bit CPU for faster and more accurate verification.

Auto sensing: Automatically recognizes fingerprints when finger is presented.

Anti-pass back: Supporting anti-pass back function.

Additional information
CPU

32 Bit RISC CPU

Template Capacity

32M standard: 60,000

Log Capacity

250,000 Events

Template size

400 bits per template

Cards Supported

125 Khz Proximity (VIRDI 4000RF)
13,56 MHz Smart Card (VIRDI 4000SC)

LCD Display

128 × 64 graphic display LCD

Communication

TCP/IP, 2 RS-232C, 1 Wiegand, 1 RS-485

Intercom interface

Yes

Lock Control

2 ports Control Motor Lock or 1 port Control EM/Strike/Deadbolt Lock

Supply voltage

Max DC 12V ~ 24V / 450mA

Operation Environment

-20 ~50° / Lower than 90% RH (Non-condensing)

Fingerprint Sensor

Optical Sensor

Sensor dimensions

13 × 15 mm

Resolution

500 dpi

Verification time (1:1)

< 0.5 s

Identification time (1:N)

< 1 s

FRR / FAR

0.1% / 0.0001%

Application

Access Control, Time & Attendance

Dimensions

181mm(W)x109mm(H)x47mm(D)

Shipping & Delivery
